10-200KW_Taizhou Kaihua Washing Machine Co.Ltd

10-200KW

Taizhou Kaihua Diesel Generator Sets Co., Ltd is one of the toppest Generator Sets in China.During these years of exporting , Taizhou Kaihua Diesel Generator Sets Co., Ltd now has rich experience in the worldwide markets

Cell Phone:+86 18762343571
WeChat/WhatsApp:+86-13912190523
Emai:marketing@kaihuagenset.com

Genset Model	Standby Power		Prime power		Engine Model	Dimention	Weight
Genset Model	KVA	KW	KVA	KW	Engine Model	mm	KG
KH-15GF	22	18	18.75	15	4B3.9-G2	11607501200	800
KH-20GF	28	22	25	20	4B3.9-G2	11607501200	800
KH-24GF	33	26	30	24	4B3.9-G2	11607501200	800
KH-32GF	44	35	40	32	4BT3.9-G2	11607501200	810
KH-48GF	69	55	60	48	4BTA3.9-G2	18607501200	850
KH-64GF	83	66	80	64	6BT5.9-G2	21608001300	1040
KH-80GF	110	88	100	80	6BT5.9-G2	21608001300	1056
KH-92GF	132	106	115	92	6BTA5.9-G2	21608001300	1096
KH-104GF	149	119	130	104	6BTAA5.9-G2	23008501300	1400
KH-150GF	198	158	187.5	150	6CTA8.3-G2	24008601380	1440
KH-180GF	220	176	225	180	6CTAA8.3-G2	25009601450	1700
KH-200GF	275	220	250	200	6LTAA8.9-G2	26409701450	2000

Model	Standby Power		Prime Power		Engine Model	Dimension	Weight
Model	KVA	KW	KVA	KW	Engine Model	Dimension	KG
KH-50GF	68.8	55	62.5	50	DB58	1800 x730x1250	810
KH-64GF	88.0	70.4	80	64	D1126	2300x790x1500	1500
KH-75GF	103.1	82.5	93.7	75	D1146T	2300x790x1500	1500
KH-90GF	123.8	99	112.5	90	D1146T	2300x790x1500	1500
KH-100GF	137.5	110	125	100	P086T1-1	2650x950x1400	1800
KH-120GF	165.0	132	150	120	P086T1-1	2650x950x1400	1800
KH-150GF	206.3	165	187.5	150	P086T1	2650x950x1400	1800
KH-200GF	275.0	220	250	200	P126T1	2960x1030x1500	2315

MODEL	Standby Power		Prime Power		Engine Model	Dimension	Weight (KG)
MODEL	KVA	KW	KVA	KW	Engine Model	Dimension	Weight (KG)
KH-40GF	55	44	50	40	BF4M2012	2000x750x1300	1050
KH-50GF	69	55	63	50	BF4M2012C	2000x750x1300	1100
KH-80GF	110	88	100	80	BF4M1013EC	2150x750x1550	1200
KH-100GF	138	110	125	100	BF4M1013FC	2150x750x1550	1380
KH-120GF	165	132	150	120	BF6M1013EC	2473x900x1546	1330
KH-150GF	206	165	188	150	BF6M1013FC G2	2600x1010x1700	1820
KH-160GF	220	176	200	160	BF6M1013FC G3	2600x1010x1700	1820
KH-180GF	248	198	225	180	BF6M1015-LA GA	2600x1140x1800	1880
KH-200GF	275	220	250	200	BF6M1015C-LA G1A	3060x1315x2035	2300
KH-220GF	303	242	275	220	BF6M1015C-LA G2A	3060x1315x2035	2300
KH-250GF	344	275	313	250	BF6M1015C-LA G3A	3060x1315x2035	2300
KH-280GF	385	308	350	280	BF6M1015C-LA G4	3060x1315x2035	2300
KH-300GF	413	330	375	300	BF6M1015CP-LA G	3060x1315x2035	2300
KH-350GF	481	385	438	350	BF8M1015C-LA G1A	3208x1515x1975	2870
KH-360GF	495	396	450	360	BF8M1015C-LA G2	3208x1815x1978	3190
KH-380GF	523	418	475	380	BF8M1015CP-LA G1A	3208x1815x1978	3190
KH-400GF	550	440	500	400	BF8M1015CP-LA G2	3208x1815x1978	3190
KH-410GF	564	451	513	410	BF8M1015CP-LA G3	3208x1815x1978	3190
KH-430GF	591	473	538	430	BF8M1015CP-LA G4	3208x1815x1978	3190
KH-450GF	619	495	563	450	BF8M1015CP-LA G5	3208x1815x1978	3190
KH-550GF	756	605	688	550	HC12V132ZL-LAG1A	4000x1850x2015	4120
KH-600GF	825	660	750	600	HC12V132ZL-LAG2A	4000x1850x2015	4120

Genset Model	Standby Power		Prime Power		Engine Model	Dimension	Weight (KG)
Genset Model	KVA	KW	KVA	KW	Engine Model	Dimension	Weight (KG)
KH-8GF	11	8.8	10	8	403A-11G1	1100x450x940	290
KH-10GF	13.75	11	12.5	10	403A-15G1	1200x500x1000	380
KH-16GF	22	17.6	20	16	404A-22G1	1350x530x1000	456
KH-20GF	27.5	22	25	20	1103A-33G	1740x730x1565	762
KH-24GF	33	26.4	30	24	1103A-33G	1740x730x1565	762
KH-36GF	49.5	39.6	45	36	1103A-33TG1	2030x730x1565	870
KH-50GF	68.75	55	62.5	50	1104A-44TG1	2135x730x1595	978
KH-64GF	88	70.4	80	64	1104A-44TG2	2135x730x1595	1018
KH-80GF	110	88	100	80	1104C-44TAG2	2235x730x1595	1090
KH-100GF	137.5	110	125	100	1106A-70TG1	2565x730x1575	1376
KH-120GF	165	132	150	120	1106A-70TAG2	2565x730x1575	1416
KH-140GF	192.5	154	175	140	1106A-70TAG3	2645x730x1630	1644
KH-160GF	220	176	200	160	1106A-70TAG4	2645x730x1630	1644
KH-180GF	247.5	198	225	180	1506A-E88TAG2	3035x900x1525	1695
KH-200GF	275	220	250	200	1506A-E88TAG3	3035x900x1525	2035

Genset Model	Standby Power		Prime power		Engine model	Dimension	Weight (KG)
Genset Model	KVA	KW	KVA	KW	Engine model	Dimension	Weight (KG)
KH-68GF	93.5	74.8	85	68	TAD530GE	2080x720x1450	1090
KH-75GF	103.1	82.5	93.75	75	TAD531GE	2080x720x1450	1150
KH-80GF	110.0	88	100	80	TAD531GE	2080x720x1450	1150
KH-90GF	123.8	99	112.5	90	TAD532GE	2280x900x1450	1250
KH-100GF	137.5	110	125	100	TAD532GE	2280x900x1450	1250
KH-120GF	165.0	132	150	120	TAD731GE	2400x870x1450	1560
KH-150GF	206.8	165	188	150	TAD732GE	2600x1050x1500	1600
KH-180GF	247.5	198	225	180	TAD733GE	2600x1050x1670	1800
KH-200GF	275.0	220	250	200	TAD734GE	2600x1120x1770	2700
